bs Series Six Color Flexographic Printing Machine

bs Series Six Color Flexographic Printing Machine
bs Series Six Color Flexographic Printing Machine
Product Code : PRINTER2
Product Description

With the assistance of our competent workforce, we have been committed to supply tough built Six Color Flexographic Printing Machine. In order to meet the international quality standards, this machine is fabricated employing latest technology at our vendors' end. Available in different sizes and models, this machine is highly demanded by number of clients. This machine is extensively used for printing purposes. Clients can avail this Six Color Flexographic Printing Machine at most economical price.

Striking attributes:

  • Simple to operate

  • Seamless finish

  • Longer functional life

Other details:

Performance:

Introduce sensitization resin as flexible printing plate, suitable for printing such packing materials as polyethylene, polypropylene bag, cellophane and roll paper, etc. It is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.
Features:
1. Easy operation, flexible starting, accurate color register.
2. The meter counter can set printing quantity according to the requirements. Stop the machine automatically at the quantity or when the material is cut off.
3. Pneumatic printing cylinder lift and lower, it will stir the printing ink automatically after lifting.
4. The printing ink is spread by the anilox cylinder with even ink color.
5. Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.
6.360°continuous and adjustable longitudinal register device.
7. The frequency control of motor speed adapts to different printing speeds.
8. There are Jogging/Stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.
9. Magnetic powder brake for unwinding tension control,magnetic powder clutch for rewinding tension control.
10. With double unwinding &rewinding shaft
Main Technical Parameter:
Type
YT-6600
YT-6800
YT-61000
Max.Effective Printing Width
560mm
760mm
960mm
Max.Web Width
600mm
800mm
1000mm
Max.Printing Speed
50m/min
50m/min
50m/min
Max.Mechanical Speed
60 m/min
60 m/min
60 m/min
Max.Diameter of Roll Material
450mm
450mm
450mm
Internal Diameter of Roll Core
76mm
76mm
76mm
Rang of Repeat Printing Length
191-914mm
191-914mm
191-914mm
Accuracy of Registration
±0.5mm
±0.5mm
±0.5mm
Plate Thickness
2.38mm
2.38mm
2.38mm
Heating Power
9Kw
13.5Kw
18Kw
Total Power
15Kw
19.5Kw
24Kw
Weight
3500kg
4200kg
5000kg
Overall Dimension
(L � W � H )mm
4300�1700�2950
4300�1900�2950
4300�2100�2950
